Reference Manual
00809-0100-4444, Rev AC
Section 6: Advanced Diagnostics Configuration
January 2015
Advanced Diagnostics Configuration
6.13 SMART Meter Verification measurements
The SMART Meter Verification test will make measurements of the coil resistance, coil signature,
and electrode resistance and compare these values to the values taken during the sensor
signature process to determine the sensor calibration deviation, the coil circuit health, and the
electrode circuit health. In addition, the measurements taken by this test can provide additional
information when troubleshooting the meter.
Coil circuit resistance
The coil circuit resistance is a measurement of the coil circuit health. This value is compared to the
coil circuit resistance baseline measurement taken during the sensor signature process to
determine coil circuit health. This value can be continuously monitored using continuous
SMART Meter Verification.
Table 6-3. Continuous SMART Meter Verification Test Parameters
Parameter
LOI menu path
(Diagnostics, Variables, MV Results, Continual Res,...)
Traditional
Fast keys
Device Dashboard
Fast keys
1 Continuous Limit Test Criteria 1,2,3,2,2,2,1 3,4,2,2
2 Simulated Velocity Sim Velocity 1,2,3,2,2,2,2 3,2,4,3,1
3 Actual Velocity ActualVelocity 1,2,3,2,2,2,3 3,2,4,3,2
4 Velocity Deviation Flow Sim Dev 1,2,3,2,2,2,4 3,2,4,3,3
5 Coil Signature Coil Inductnce 1,2,3,2,2,2,5 3,2,4,2,2
6 Sensor Cal Deviation Sensor Cal Dev 1,2,3,2,2,2,6 3,2,4,2,3
7 Coil Resistance Coil Resist 1,2,3,2,2,2,7 3,2,4,2,1
8 Electrode Resistance Electrode Res 1,2,3,2,2,2,8 3,2,4,2,4
9 mA Expected 4-20 mA Expect 1,2,3,2,2,2,9 3,2,4,4,1
10 mA Actual 4-20 mA Actual 1,2,3,2,2,2,--
(1)
(1)To get to this value, use the down arrow to scroll through the menu list
3,2,4,4,2
11 mA Deviation AO FB Dev 1,2,3,2,2,2,--
(1)
3,2,4,4,3
LOI menu path
Manual: Diagnostics, Advanced Diag, Meter Verify, Measurements, Manual
Measure, Coil Resist
Continuous: Diagnostics, Advanced Diag, Meter Verify, Measurements,
Continual Meas, Coil Resist
Traditional fast keys Manual: 1,2,3,2,5,1,1
Continuous: 1,2,3,2,5,2,1
Device dashboard Manual: 3,4,1,3,1
Continuous: 3,2,4,2,1
