HOW TO READ THE AT10.1 MODEL NUMBER
GROUP I RATINGS (6-25 Adc)
Your AT10.1 model number is coded to describe the options that are included. Please find the model
number on the data nameplate and write it in the spaces provided below. Then follow the chart to
determine the configuration of your battery charger.
AT10
A B C D E F K L M N P Q R
DESCRIPTION CODE FEATURE
DESCRIPTION CODE FEATURE
A
SERIES AT10 AT10.1 CHARGER S STANDARD
012 12 Vdc M MEDIUM AIC
024 24 Vdc
F
CIRCUIT
BREAKER
RATING
(SEE TABLE)
H HIGH AIC
048 48 Vdc
B
NOMINAL
DC OUTPUT
VOLTAGE
130 130 Vdc AUX SUPPLIED
006 6 Adc
K
AUX ALARM
RELAY BOARD
XXX NOT SUPPLIED
012 12 Adc
016 16 Adc G SUPPLIED
020 20 Adc
L
GROUND PAD
X NOT SUPPLIED
C
NOMINAL
DC OUTPUT
CURRENT
025 25 Adc
U UNFILTERED L SUPPLIED
F FILTERED
M
LIGHTNING
ARRESTOR
X NOT SUPPLIED
D
FILTERING
E ELIMINATOR
120 120 Vac 60 Hz
1
F INCLUDED
208 208 Vac 60 Hz
1
N
FUNGUS
PROOFING
X NOT INCLUDED
240 240 Vac 60 Hz
1
S INCLUDED
480 480 Vac 60 Hz
2
P
STATIC
PROOFING
X NOT INCLUDED
220 220 Vac 50/60 Hz
3
380 380 Vac 50/60 Hz
3
Q
NOT USED X
E
AC INPUT
VOLTAGE
416 416 Vac 50/60 Hz
3
R
CANADIAN C BILINGUAL LABELING
DESCRIPTION CODE FEATURE
DESCRIPTION CODE FEATURE
1 - 120/208/240 Vac multi-tap input - Unit is wired and shipped from factory at specified voltage.
2 - 480 Vac input requires addition of medium or high ampere interrupting capacity circuit breakers.
3 - Special order - Please consult factory for availability.
INPUT AND OUTPUT CIRCUIT BREAKER INTERRUPTING RATINGS
CODE TYPE
AC RATINGS
(ALL INPUT VOLTAGES)
DC RATINGS
(125 Vdc)
S STANDARD 240 Vac: 10,000 AIC
10,000 AIC
4
5,000 AIC
5
M MEDIUM AIC
240 Vac: 25,000 AIC
480 Vac: 18,000 AIC
10,000 AIC
H HIGH AIC
240 Vac: 65,000 AIC
480 Vac: 25,000 AIC
25,000 AIC
4 - Rating applies to 130Vdc 16-25 Adc units.
5 - Approximate rating applies to all other units.
NOTE:
The model number listed on the charger data nameplate does not include any field-installed
options. Also, certain accessories are not included in the model number, even if they are shipped with the
charger. Check off below any accessories that were included, or that you install yourself.
Enclosure drip shield assembly NEMA-4/12/13 type enclosure
Floor mounting brackets Pad lock for front panel door
Rack mounting brackets External temperature compensation probe
Cabinet heater assembly DNP3 Level 2 / Modbus communications module
Please find the serial number on the
data nameplate and record it here:
