3-54
Rev 1
If it is required to set the time:
1.Select the SET 2 page on the left side.
2.Press the left Cto turn on the left cursor function if it
is not on already.
3.Use the left outer knob to position the cursor over the
time zone (figure 3-169).
4.Use the left inner knob to change the time zone, if
desired (figure 3-170). A listing of the time zones and
their abbreviations is contained in section 3.2.
5.Turn the left outer knob one step counterclockwise to
position the cursor over the time (figure 3-171).
6.Rotate the left inner knob to select the correct hour
(figure 3-172). Remember, the KLN 90B uses 24 hour
time. If it is 1:00 P.M. or later, add 12 hours (for
example, 2:30 P.M. becomes 14:30).
7.Turn the left outer knob one step clockwise to position
the flashing part of the cursor over the first minute’s
position, and then use the left inner knob to select the
correct value (figure 3-173).
8.Turn the left outer knob one step clockwise again to
position the flashing part of the cursor over the
remaining minute’s position, and then use the left
inner knob to complete the time selection.
9.Press Eto start the clock running (figure 3-174).
10.Press the left Cto turn off the left cursor function.
DATE/TIME |
|
11 SEP 94|
21:23:04UTC|
CORD UNIV/Z|
|
CRSR
Figure 3-169
DATE/TIME |
|
11 SEP 94|
16:23:04CDT|
CENTRAL DAY|
|
CRSR
Figure 3-170
DATE/TIME |
|
11 SEP 94|
18:!!:04CDT|
CENTRAL DAY|
|
CRSR
Figure 3-172
DATE/TIME |
|
11 SEP 94|
18:37:04CDT|
CENTRAL DAY|
|
CRSR
Figure 3-174
DATE/TIME |
|
11 SEP 94|
18:3!:04CDT|
CENTRAL DAY|
|
CRSR
Figure 3-173
DATE/TIME |
|
11 SEP 94|
16:23:04CDT|
CENTRAL DAY|
|
CRSR
Figure 3-171
