3-25
Rev 1
4. Turn the right inner knob to display the first character
of the waypoint name, “N” in this case (figure 3-78).
5. Turn the right outer knob one step clockwise and then
use the right inner knob to enter the second character,
“A” (figure 3-79).
6. Use the right outer knob and right inner knob as
before to select the third character, “P”, and fourth
character, “O” (figure 3-80). Up pops Napoleon and
its identifier, ANX!
7. Press the right C to turn off the cursor function so
you can view other pages.
We will now use another example to show how we may
enter a few characters and then scan through all the way-
points in the database beginning with those characters.
Let’s use this method to find the Newport News airport
located in Newport News, VA.
1. Use the right outer knob to select the airport type way-
points. If the APT 1 page is not displayed, use the
right inner knob to select the APT 1 page. The airport
displayed at this time is not important.
2. Press the right C to bring the cursor on the display.
3. Rotate the right outer knob to locate the cursor over
the first character in the airport name (figure 3-81).
4. Turn the right inner knob to display an “N”.
5. Use the right outer and inner knobs to enter a “E” in
the second character position and an “W” in the third
character position.
6. Rotate the right outer knob one step clockwise to
locate the cursor over the fourth character position
(figure 3-82).
You will now scan through all the airport names begin-
ning with “NEW”.
7. Pull the right inner knob to the “out” position (figure 3-
83).
8. Turn the right inner knob (in the “out” position) to scan
through all the airport names beginning with “NEW”.
There are about seventy-nine of them. Not too good
you say. We can make it a lot easier to find Newport
News if we enter another character.
9. Push the right inner knob back to the “in” position.
10.Use the right inner knob to select a “P” in the fourth
character position.
|PNE
|N PHILADELP
|HIA T
|112.00 10^W
|N 40^04.92'
|W 75^00.60'
CRSR
Figure 3-78
| ABB D
|NABB
| L
|112.40 1^E
|N 38^35.33'
|W 85^38.16'
CRSR
Figure 3-79
| ANX D
|NAPOLEON
| L
|114.00 7^E
|N 39^05.73'
|W 94^07.72'
CRSR
Figure 3-80
| M01
|GEN SPAIN
|
|CL B
|N 35^12.08'
|W 90^03.09'
CRSR
Figure 3-81
| M72
|NEW ALBANY-
|UNION
|
|N 34^32.83'
|N 34^32.83'
CRSR
Figure 3-82
| M72
|NEW ALBANY-
|UNION
|
|N 34^32.83'
|W 89^01.45'
CRSR
Figure 3-83
