2-6
Rev 1
8. Press E to acknowledge the estimated load time
and begin erasing the existing database. The unit will
now display ERASING DATA BASE (figure 2-6). After
the database has been erased, loading of the new data
begins automatically. As the new data is being loaded,
the percentage of transfer is displayed (figure 2-7).
9. Monitor the computer screen. When the first disk is
complete the computer screen will display “Insert Disk 2
then press any key to continue.” Disk 1 should now be
removed from the disk drive and disk 2 should be
inserted. Press any key on the computer. The load oper-
ation will continue. If there are 3 disks the computer
screen will prompt when to use disk 3.
10. The KLN 90B will indicate when the database update
is complete as shown in figure 2-8. The computer screen
will display the new database expiration date. You may
either turn the KLN 90B off at this point or press E to
restart the KLN 90B.
11. Remove the interface cable. Remove the disk from
the computer. Turn off the computer.
The chances are small of having difficulty updating the
database but if you have a problem:
First check that the interface cable is properly connected
and that the computer is turned on. If there is a problem
with the connection or the computer the KLN 90B will dis-
play LOADER NOT READY. When the problem is cor-
rected this prompt is removed and the update operation
can continue from where it left off.
If the wrong disk is inserted the computer screen will dis-
play “Incorrect Disk - please insert disk __.”, where the
number 2 or 3 is inserted in the blank.
If an internal test fails after the data has been loaded, the
KLN 90B will display CHECKSUM ERROR, DATA BASE
INVALID, ACKNOWLEDGE?. Press E to acknowl-
edge. The KLN 90B will then display RETRY and EXIT.
Use the left outer knob to position the cursor over the
desired choice and press E.
There are other error messages that may be displayed. If
you have a problem that you can’t resolve, write down
any error messages to aid your Bendix/King Service
Center in identifying the problem.
U P D A T E
D A T A B A S E
E R A S I N G
D A T A B A S E
SET 0
Figure 2-6
U P D A T E
D A T A B A S E
14 PERCENT COMPLETE
SET 0
Figure 2-7
U P D A T E
D A T A B A S E
UPDATE PUBLISHED DB
COMPLETED
ACKNOWLEDGE?
CRSR ent
Figure 2-8
