USA only:
This device has been approved by the FCC
as a “Vehicular Radar System”. The radar
sensor is intended for use in an automotive
radar system only. Removal, tampering, or
altering of the device will void any
warranties, and is not permitted by the
FCC. Do not tamper with, alter, or use in
any non-approved way.
Any unauthorized modification to this
device could void the user’s authority to
operate the equipment.
i
Canada only:
This device complies with RSS-210 of
Industry Canada. Operation is subject to
the following two conditions:
1. This device may not cause interference,
and
2. this device must accept any
interference received, including
interference that may cause undesired
operation of the device.
Removal, tampering, or altering of the
device will void any warranties, and is not
permitted. Do not tamper with, alter, or use
in any non-approved way.
Any unauthorized modification to this
device could void the user’s authority to
operate the equipment.
Sensor monitoring range
The Blind Spot Assist is able to monitor a
range up to 10 ft (3 m) to the rear and both
sides of the vehicle.
G
Warning!
The Blind Spot Assist monitors certain
areas in the immediate vicinity of your
vehicle. Vehicles approaching and passing
at speeds that exceed the speed of your
vehicle significantly will not be detected.
There will be no warning display and no
audible warning.
When driving in a very wide lane, the
sensors may not be able to cover the entire
width of the neighboring lane. Vehicles
driving on the outside of the neighboring
lane may not be detected.
It is the driver’s responsibility at all times to
be attentive to road, weather and traffic
conditions and to provide the steering,
braking and other driving inputs necessary
to retain control of the vehicle. Failure to do
so could result in recognizing dangers too
late, possibly resulting in an accident and
serious injury to yourself and others.
When driving in a very narrow lane, the
sensors may detect and display vehicles in
the second lane over. This will be the case
if there are vehicles driving on the inside
edge of their lane.
The Blind Spot Assist sensors are built into
the front and rear bumpers. Make sure that
the area of the bumpers around the sensors
is free of dirt, ice and snow. The radar sensors
must not be obstructed, for example, by
bicycle carriers or overhanging luggage.
