Power windows
326
X
Switch on the ignition.
X
Opening/Closing: Press or pull and hold
switch 1 to 4 to the resistance point.
The corresponding window will move
downwards or upwards until you release
the switch.
X
Express operation: Press or pull switch
1 or 2 past the resistance point and
release.
The corresponding door window opens or
closes completely.
X
Express opening of rear side windows:
Press switch 3 or 4 past the resistance
point and release.
The corresponding side window opens
completely.
X
Stopping during express operation:
Press or pull the respective switch again.
Closing when a window is blocked
G
Warning!
Make sure that nobody can become
trapped and be seriously or even fatally
injured when closing a window with greater
force or without automatic reversal
function.
If the upward movement of a window is
blocked during the closing procedure, the
window will stop and open slightly. However,
the door window will exert greater force
before reversing than when the door window
is closed in express operation. Please
exercise caution!
X
Immediately after the window has stopped
because it was blocked, pull the respective
switch upwards until the window is fully
closed.
If the door window is blocked again and opens
slightly:
X
Immediately after the window was blocked,
pull the respective switch upwards until the
window is fully closed.
G
Warning!
Pressing and holding the switch to close the
window immediately after it had been
blocked two times will cause the window to
close without any reversal function for as
long as you hold the switch.
Synchronizing power windows
The windows must be synchronized if they
cannot be fully closed (express operation).
Each window must be synchronized
separately.
X
Close all doors.
X
Switch on the ignition.
X
Pull and hold switch 1, 2, 3 or 4
(Y page 325) until the respective window is
closed.
The window opens again slightly.
X
Pull and hold the respective switch once
more immediately until the window is
completely closed.
X
Hold the respective switch for
approximately 1 second.
The window is synchronized.
Controls in detail
