COMAND seats
229
Drive-dynamic multicontour seats
i
If PRE-SAFE
®
has been activated, the air
pressure in the air chambers (sides of seat
cushion and seat backrest) of the drive-
dynamic multicontour seats is increased.
Drive-dynamic multicontour seats allow
several individual support adjustments and
can automatically adjust lateral support to
your driving style (Y page 230).
i
Whether adjustments are being made
manually or automatically, noises may
result from pumping air into or releasing air
out of the air chambers.
Multicontour adjustments
To support the spine, you can individually
adjust the seat backrest contour of the front
seats by regulating the air pressure in the air
chambers.
The settings are made on the COMAND
display.
You can adjust the following air chambers:
R
sides of seat cushion
R
sides of seat backrest
R
seat backrest curvature in lumbar area
R
seat backrest curvature in shoulder area
Adjusting sides of seat cushion
This function is used to adjust the air
chambers in the sides of the seat cushion.
X
Select seat (Y page 227).
X
Selecting Seat sides: Slide omp or
rotate ymz.
X
Confirming selection: Press n.
A scale appears.
1
Scale
2
Cursor
3
Current setting
X
Slide qmr or rotate ymz until desired
setting is reached.
X
Saving setting: Press n.
Adjusting seat backrest sides
This function is used to adjust the air
chambers in the seat backrest sides.
X
Select seat (Y page 227).
X
Selecting Seatback Sides: Slide qmr or
rotate ymz.
X
Confirming selection: Press n.
A scale appears.
X
Slide qmr or rotate ymz until desired
setting is reached.
X
Saving setting: Press n.
Control systems
