When Map Orientation
is set to North Up, the
boat icon rotates accord-
ing to its COG direction,
with respect to north; the
map does not rotate.
When Map Orientation is set to Track-Up, the boat icon al-
ways points up while the map rotates so the top of the screen
is always the COG direction. The map rotates every time COG
changes more than 10 degrees.
When Map Orientation is set to Course Up, the map is ro-
tated so the active course line is a vertical line and the top of
the screen is the bearing to the destination waypoint.
Press the MENU softkey, use the CURSOR KEY to high-
light Map Setup and press ENTER.
Use the CURSOR KEY to highlight Map Orientation, press
ENTER.
Use the CURSOR KEY to highlight North Up, Track Up or
Course Up and press ENTER.
Default setting: North Up
Projected Course Indicator
The position of the boat can be projected ahead in time based
on current velocity. The projected course is represented by a
solid line extending from the boat in the direction of its COG
and terminated with an
.
Press the MENU softkey, use the CURSOR KEY to high-
light Map Setup and press ENTER. Use the CURSOR KEY
to highlight Projected Course and
press ENTER. The course can be
projected ahead over 2 min., 10
min., 30 min., 1 hour, or 2 hours.
Use the CURSOR KEY to high-
light and ENTER to accept. Press
QUIT to exit.
Default setting: OFF
Map Shift
The position plotted on the map screen and the electronic
charts on the C-Cards are based on WGS 1984 datum re-
gardless of the datum set. Paper charts from which electronic
charts are created may be based on other datums and were
shifted to WGS 1984 when the electronic charts were cre-
ated. In some rare cases, the datum of the paper chart is un-
known, which may cause a consistent bias (error) to appear
between the displayed position and known coordinates. This
bias can be corrected by using Map Shift to shift the receiver’s
computed position to match its coordinates on your paper
chart.
MAP ORIENT
North Up
Track Up
Course Up
PROJECTED CRS
Off
2 Minutes
10 Minutes
30 Minutes
1 Hour
2 Hours
