Magellan NAV 600012
The dashed line has become
a solid line. From this point,
more legs could be added (ap-
pended) to the route in the
same way. In this example, we
have created a two-leg route.
Press
DONE
to complete
the Create Route function.
Moving a Waypoint. Press
EDIT
to access the Route
Edit mode. Move the cursor to-
ward WPT003 and when the
circle appears around the
waypoint, press
MOVE
. As
you move the cursor away from
WPT003, a dashed line aids you
in placing it.
When you have moved the
cursor to the new waypoint
position, press
ENTER
. The
waypoint has been moved
and the route recalculated.
Inserting a Waypoint. A
waypoint can be inserted in a
route. To accomplish this, move
the cursor until it is close to the
leg where the new waypoint will
be inserted and the Insert
softkey becomes active.
MANUAL MOVE INSERT REMOVE
n
m
n
m
K
t
°
°
TO CURSOR SCALE 90.0
BRG
125
DST
9.56
COG
346
SOG
0.0
33 09.41 N 117 36.24 W
WPT001
WPT002
WPT003
ENTER to append Quit to exit
ENTER to append Quit to exit
MANUAL MOVE INSERT REMOVE
n
m
n
m
°
WPT001
WPT002
WPT003
TO: WPT003 SCALE 90.0
BRG
107
DST
22.3
CURSOR
33 05.05 N 117 21.00 W
ENTER to move Quit to exit
n
m
n
m
K
t
°
°
TO CURSOR SCALE 243
BRG
107
DST
22.3
COG
346
SOG
0.0
33
°
05.05 N 117
°
21.00 W
WPT001
WPT002
WPT003
MANUAL
ENTER to append Quit to exit
n
m
n
m
°
TO: WPT003 SCALE 90.0
BRG
193
DST
11.2
CURSOR
33
°
01.48N 117
°
31.47W
WPT001
WPT002
WPT003
MANUAL
BCKTRK
DONE
