To view additional information on the Objects shown in the
QUICK INFO window, press
ALLINF
and a full-screen win-
dow opens, showing a list of the objects under the cursor.
When the ALLINF softkey is pressed, the objects and their
attributes appear.
Sometimes a single object,
such as a floating Navigation
mark, may contain several
navigational aids such as a
buoy, a radar transponder
beacon, a light, and a fog sig-
nal. In this case, when you
press
ALLINF
, the ‘Naviga-
tion Mark Afloat’ appears at
the top of the screen and the
individual navaids are listed
below along with their at-
tributes. If there is additional
information on other pages,
you can use the PAGEDN softkey to display them.
When you have finished viewing attributes, press
QUIT
or
DONE
to return to the map screen.
When using an in-land cartridge, major highways will be
shown as you zoom into low scales. To obtain a detailed de-
scription of the highway, zoom into a scale lower than 10
miles and place the cursor over the highway and its descrip-
tion will appear on the quick information window.
Navigation mark
afloat
Buoy, safe water
Colour of navigational mark
red/white
Object none
NWP
Light
Colour
white
Light characteristic
morse
Signal group
(!)
Value of nominal range
5.0 Miles
Navigation mark
fixed
Extended
PAGEUP PAGEDN DONE
