Electrical system S 65 AMG
Spark plugs,
electrode gap
0.028 in (0.7 mm)
Spark plugs,
tightening torque
15 - 22 lb-ft
(20 - 30 Nm)
Main dimensions S 65 AMG
Overall vehicle
length
207.1 in (5 261 mm)
Overall vehicle
width
57
83.5 in (2 120 mm)
Overall vehicle
height
58.7 in (1 490 mm)
Wheelbase
124.6 in (3 165 mm)
Track, front
63.0 in (1 600 mm)
Track, rear
63.2 in (1 606 mm)
Turning circle
40.0 ft (12.2 m)
Weights S 65 AMG
Roof load
max. 220 lb (100 kg)
Trunk load
max. 220 lb (100 kg)
Rims and tires
Notes
!
Only use tires which have been tested and
approved by Mercedes-Benz. Tires
approved by Mercedes-Benz are developed
to provide best possible performance in
conjunction with the driving safety systems
on your vehicle such as the ABS or the ESC.
Tires specially developed for your vehicle
and tested and approved by Mercedes-
Benz can be identified by finding the
following on the tire’s sidewall:
R
MO = Mercedes-Benz Original
equipment tires
Using tires other than those approved by
Mercedes-Benz may result in damage that
is not covered by the Mercedes-Benz
Limited Warranty.
!
Using tires other than those approved by
Mercedes-Benz can have detrimental
effects, such as
R
poor handling characteristics
R
increased noise
R
increased fuel consumption
Moreover, tires and rims not approved by
Mercedes-Benz may, under load, exhibit
dimensional variations and different tire
deformation characteristics that could
cause them to come into contact with the
vehicle body or axle parts. Damage to the
tires or the vehicle may be the result.
i
Further information on tires and rims is
available at any authorized Mercedes-Benz
Center. The Tire and Loading Information
placard with the recommended tire
inflation pressures for cold tires is located
on the driver’s door B-pillar. Supplemental
tire inflation pressure information for
driving at high speeds or for vehicle loads
less than the maximum loaded vehicle
condition can be found on the tire inflation
pressure label. The tire inflation pressure
label is located on the inside of the fuel filler
flap. The tire inflation pressure should be
checked regularly and should only be
adjusted on cold tires. Follow tire
manufacturer’s maintenance
recommendation included with the vehicle.
For information on recommended tire
inflation pressure and supplemental tire
inflation pressure information for special
driving situations, see (Y page 411).
57
Exterior rear view mirrors folded out.
532
Rims and tires
Technical data
221_AKB; 6; 20, en-US
d2ugruen, Version: 2.11.8.1
2009-09-24T13:28:17+02:00 - Seite 532
