Engine S 550 4MATIC
Compression
ratio
10.5:1
Output acc. to
SAE J 1349
50
382 hp/6 000 rpm
(285 kW/6 000 rpm)
Maximum torque
acc. to SAE J 1349
391 lb-ft/
2 800 - 4 800 rpm
(530 Nm/
2 800 - 4 800 rpm)
Maximum engine
speed
6 500 rpm
Firing order
1-5-4-2-6-3-7-8
Poly-V-belt
2 404 mm
Electrical system S 550 4MATIC
Alternator
14 V/180 A
Starter motor
12 V/1.7 kW
Battery
12 V/95 Ah
Spark plugs, type
NGK PLKR 6A
Bosch Y 7 MPP33
Spark plugs,
electrode gap
0.031 in (0.8 mm)
Spark plugs,
tightening torque
15 - 18 lb-ft
(20 - 25 Nm)
Main dimensions S 550 4MATIC
Overall vehicle
length
206.7 in (5 250 mm)
Overall vehicle
width
51
83.5 in (2 120 mm)
Overall vehicle
height
58.2 in (1 479 mm)
Main dimensions S 550 4MATIC
Wheelbase
124.6 in (3 165 mm)
Track, front
63.0 in (1 600 mm)
Track, rear
63.2 in (1 606 mm)
Turning circle
40.0 ft (12.2 m)
Weights S 550 4MATIC
Roof load
max. 220 lb (100 kg)
Trunk load
max. 220 lb (100 kg)
Vehicle specification S 600 (221.176)
The quoted data apply only to the standard
vehicle. Contact an authorized Mercedes-
Benz Center for the corresponding data of all
special bodies and special equipment.
Engine S 600
Engine, type
275
Mode of operation
4-stroke engine,
gasoline injection
No. of cylinders
12
Bore
3.23 in (82.00 mm)
Stroke
3.43 in (87.00 mm)
Total piston
displacement
336.4 cu in
(5 513 cm
3
)
Compression
ratio
9.0:1
Output acc. to
SAE J 1349
52
510 hp/5 000 rpm
(380 kW/5 000 rpm)
50
Premium fuel required. Performance may vary with fuel octane rating.
51
Exterior rear view mirrors folded out.
52
Premium fuel required. Performance may vary with fuel octane rating.
Vehicle specification S 600 (221.176)
529
Technical data
