Example illustration: Map with route guidance
inactive and with the menu system hidden (full
screen map display)
:
Current vehicle position
;
Map orientation (Y page 103)
=
Map scale (Y page 102)
Hiding or showing the menu system
X
Hiding: Slide ZV.
The Full Screen menu item appears in
the main area of the display.
X
Press W.
or
X
Press and hold back button % in the
center console (Y page 87).
The menu system is hidden. The map can
be seen in the full screen.
X
Showing: Press W in the full-screen map
display.
Adjusting the map scale
i
It is only possible to adjust the map scale
with the menu system hidden (full-screen
map display).
X
Rotate cVd until the desired map scale is
set.
:
Currently set map scale as number
;
Scale
=
Pointer indicating the currently set map
scale
?
Previously set value (only visible when the
setting has been changed)
As soon as you rotate cVd, scale ; appears.
Rotating clockwise zooms out, rotating
counterclockwise zooms in.
Saving current vehicle position as
destination in last destinations list
X
Showing menu system, if necessary:
Press W.
X
Saving: Select Position Q Store
Vehicle Position.
COMAND saves the current vehicle
position as a destination in the last
destinations (Y page 147).
i
The cross hair may not be visible when
using this function. Otherwise the position
of the cross hair will be stored.
Moving the map
i
It is only possible to move the map with
the menu system hidden (full-screen map
display).
X
Slide ZVÆ, XVY or aVb.
A cross hair appears on the map.
102
COMAND navigation (introduction)
