Adjusting seat backrest curvature in
lumbar area
This function is used to adjust the air
chambers in the lumbar area of the seat
backrest.
X
Select seat (Y page 216).
X
Selecting Lumbar: Slide XVY or rotate
cVd.
X
Confirming selection: Press W.
Crosshair appears.
You can use them to make two settings:
R
vertical: shift the point of greatest
curvature upward or downward
R
horizontal: adjust the degree of
curvature
X
Slide ZVÆ or XVY until desired setting is
reached.
X
Saving setting: Press W.
Adjusting seat backrest curvature in
shoulder area
This function is used to adjust the air
chambers in the shoulder area of the seat
backrest.
X
Select seat (Y page 216).
X
Selecting Shoulders: Slide XVY or rotate
cVd.
X
Confirming selection: Press W.
A scale appears.
X
Slide ZVÆ or rotate cVd until desired
setting is reached.
X
Saving setting: Press W.
Drive-dynamic multicontour seats
For information on manual multicontour seat
settings, see “Multicontour seats, front”
(Y page 218).
i
If PRE-SAFE
®
has been activated, the air
pressure in the air chambers (sides of seat
cushion and seat backrest) of the drive-
dynamic multicontour seats is increased.
The drive-dynamic multicontour seat
automatically adjusts the lateral support
provided by the seat backrest to your driving
style.
The drive-dynamic multicontour seat
electronically controls the air pressure in the
air chambers of the seat backrest side
bolsters. This function improves driving
comfort and pleasure.
X
Select seat (Y page 216).
X
Selecting Dynamic Seat: Slide XVY or
rotate cVd.
X
Confirming selection: Press W.
A scale appears.
COMAND seats
