Storing positions into memory
X
Adjust the seats.
X
On the driver’s side, also adjust the
steering wheel and exterior rear view
mirrors to the desired positions.
X
Press memory button M once and within
3 seconds press memory position button
1, 2 or 3.
When the settings are stored to the
selected position, an acknowledgement
signal sounds.
Recalling positions from memory
X
Press and hold desired memory position
button 1, 2 or 3 until the seat has moved
to the stored position completely. On the
driver’s side, also wait for the steering
wheel and exterior rear view mirrors to
move to the stored position.
i
Releasing the memory position button
stops movement to the stored positions
immediately.
Lighting
Notes
i
If you drive in countries with left-hand
driving, you must have the headlamps
modified for symmetrical low beams.
Relevant information can be obtained at
any authorized Mercedes-Benz Center.
i
The active Bi-Xenon headlamps increase
usable illumination over conventional
headlamps because they follow the
curvature of the road ahead. The beams of
the active Bi-Xenon headlamps shift to
either side according to the vehicle’s
steering angle and speed.
Exterior lamp switch
1 W
Standing lamps, left
2 X
Standing lamps, right
3 $
Off
Daytime running lamp mode
4 c
Automatic headlamp mode
Daytime running lamp mode
5 T
Parking lamps
38
6 L
Low-beam headlamps or high-beam
headlamps
7 R
Vehicles without front fog lamps:
Rear fog lamp
7 N
Vehicles with front fog lamps: Front
fog lamps
8 R
Vehicles with front fog lamps: Rear
fog lamp
i
The exterior lamps (except standing
lamps or parking lamps) go out
automatically when you remove the
SmartKey from the starter switch or open
the driver’s door with the ignition switched
off.
When the parking lamps or the rear fog
lamp are switched on and you remove the
SmartKey from the starter switch and open
the driver’s door, an acoustic signal
sounds.
In addition, the message Please Switch
Off Lights appears in the multifunction
display.
38
When the parking lamps are on, the tail lamps, the license plate lamps, the side marker lamps, and the
instrument cluster illumination are also on.
