If the air conditioning cannot be activated
again, this indicates that the air
conditioning is losing refrigerant. The
compressor has turned off.
Have the air conditioning checked at the
nearest authorized Mercedes-Benz Center.
Selecting Mono mode
Mono is used to adjust the climate zones for
the entire vehicle at the same time. When the
Mono function is switched on and you change
the climate on the driver’s side, these
changes will be carried out in the same
manner for all climate zones.
X
Select climate control settings Q Central
climate control menu.
X
Selecting Mono: Slide ZVÆ or rotate
cVd.
X
Confirming selection: Press W.
A checkmark appears when the function
has been selected.
X
Exiting menu: Press back button % in
the center console (Y page 77) or slide
XVY.
The Mono function is automatically switched
off when you:
R
change a climate control setting for the
front passenger side using COMAND
R
operate a button from the climate control
for the front passenger side
R
operate one of the buttons for the rear
climate control system
Adjusting footwell temperature
i
In automatic mode, this setting optimizes
the footwell temperature when outside
temperatures are low.
The Footwell Temperature function is used
to adjust the temperature difference between
the footwell and the rest of the passenger
compartment.
The higher the selected value, the higher the
temperature in the footwell will be.
X
Select climate control settings Q Central
climate control menu.
X
Selecting Footwell Temperature: Slide
ZVÆ or rotate cVd and then press W.
X
Changing temperature difference: Slide
ZVÆ or rotate cVd.
X
Exiting menu: Press W, back button
% in the center console (Y page 77) or
slide XVY.
The setting is saved.
214
COMAND automatic climate control
