mate GPS PN-20.
Information Field Option Description
Bearing The direction of travel from the current location to the desti-
nation (finish or next stop). Expressed in degrees.
Displays a green arrow pointing in the direction of the next
waypoint or route point. The arrow is grayed out when no
movement is reported by the device. It is green when the
device is moving.
Coordinates: Primary The coordinates for the current GPS location, cursor position,
or map center in the primary format. The default is Lat/
Lon. You can change the format in Device Setup>
Units>Coordinates: Primary.
Coordinates: Secondary The coordinates for the current GPS location, cursor position,
or map center in the secondary format. The default is
UTM/UPS. You can change the format in Device Setup>
Units>Coordinates: Secondary.
Course The direction of travel on a route from the starting location to
the destination (finish or next stop). Expressed in degrees.
Device Odometer The total distance traveled in all trips.
Distance to Finish The distance from the current location to the route finish.
Distance to Next Stop The distance from the current location to the next stop in the route.
Distance to Next Turn The distance from the current location to the next turn in the route.
Elevation The altitude (height) above or below sea level. Expressed in
distance.
Elevation: Maximum The maximum elevation achieved. Expressed in distance.
This field may be reset when you clear Trip Info.
Elevation: Minimum The minimum elevation achieved. Expressed in distance.
This field may be reset when you clear Trip Info.
Information Field Option Description
ETA at Finish The Estimated Time of Arrival at the route finish. Expressed
as hours:minutes AM/PM. ETA is based on the current
device time, not on the local time at the destination.
ETA at Next Turn The Estimated Time of Arrival at the next turn in the route.
Expressed as hours:minutes AM/PM. ETA is based on the
current device time, not on the local time at the turn.
ETA at Next Stop The Estimated Time of Arrival at the next stop in the route
Expressed as hours:minutes AM/PM. ETA is based on the
current device time, not on the local time at the next stop.
Finish The Finish label as it appears in the route directions.
GPS Accuracy The calculated accuracy of the GPS. Expressed in distance.
GPS Status The current status of your GPS device. No Fix, 2-D, or 3-D.
Heading The current direction of travel. Expressed in degrees.
Moonrise/Moonset The time of day at which the moon will rise and set.
Expressed as hours:minutes AM/PM. This information is
calculated for the specific geographic area where the GPS
has acquired a 3-D fix.
Next Stop The label for the next stop as it appears in the route directions.
Next Turn The label for the next turn as it appears in the route directions.
Also displays an arrow showing the direction of the turn/
route direction information.
Next Turn Arrow The arrow representing the next turn as it appears in the
route directions. No label text displays.
Off Course The perpendicular distance between the current location
and the route. Expressed in distance.
Speed The current rate of travel for the device. Expressed in
distance per unit of time.
The Map Page
