Sonar view options
Select the View in the Sonar menu to see View options.
Split screen options
Zoom
Key Description
1 Zoom level
2 Zoom bars
The Zoom mode presents a magnified view of the sounder image
on the left side of the panel. By default the zoom level is set to 2x.
You can select up to 8x zoom from the drop-down menu, using the
+/- keys, or the zoom (+ or -) buttons. The range zoom bars on the
right side of the display shows the range that is magnified. If you
increase the zooming factor the range is reduced. You see this as
reduced distance between the zoom bars.
70
Sonar | HDS Gen3 Operator Manual
