5700/5800 GPS Receiver User Guide 15
Setting up the Receiver 3
5700 GPS Receiver Operation
Figure 3.5 Bottom panel
The CompactFlash/USB door conceals the CompactFlash port and
USB port. To open the door, push the catch on the front panel down.
C
WARNING – When no USB cable is connected, or when using the receiver
in a harsh environment, keep this door closed to keep moisture, dust, and
dirt out of the ports. The temperature rating of the receiver applies only
when all doors on the receiver are closed.
3.2 Setup Guidelines
Consider the following guidelines when setting up the 5700 receiver.
CompactFlash port
USB port
Internal battery
compartment
Internal battery
CompactFlash/
USB door
