The 360° HSI contains a Course Deviation Indicator (CDI), with a Course
Pointer, To/From Indicator, and a sliding deviation bar and scale. The course
pointer is a single line arrow (GPS1, VOR1, and LOC1) or a double line arrow
(GPS2, VOR2, and LOC2) which points in the direction of the set course. “LOC”
will automatically be displayed if a localizer frequency is tuned. The To/From
arrow rotates with the course pointer and is displayed when the active NAVAID
is received.
2.6.1 Setting the Heading Bug
The Selected Heading is shown to the upper left of the HSI for 3 seconds
after being adjusted. The light blue bug on the compass rose corresponds to the
Selected Heading.
New Heading Bug Setting
Heading Bug
Current Heading
Figure 2-21 Heading Bug Setting
1) Press the HDG key to activate HDG mode.
2) Turn the PFD knob to change the Heading Bug.
Or
3) Press the PFD knob in HDG mode to set the Heading Bug to the current
heading.
