MATE-DISPLAYED MX60 STATUS MODE Screens
The MX60 STATUS MODE Screens displayed on the optional OutBack MATE include MODE, METER, and
SET (SETPOINT). In STATUS Mode, these MX functions can be viewed by the MATE, but not changed.
Please see the MATE Installation and User Manual for more information.
MX MODE Screens
• charger mode: displays one of ve charging stages (Bulk, Absorption, Float, Silent, or Equalization)
• aux relay mode: displays one of eight MX60 AUX modes (Manual, Vent Fan, PV Trigger, Float, ERROR
ALARM, Diversion, Low Batt(ery) Disconnect, or Remote)
• aux relay state: indicates if the AUX is ON or OFF
Press <METER> to view
the MX METER screens.
MAIN------------------------
12:00:30P
SUM STATUS SETUP ADV
STATUS………………………
choose product:
FX MX
STATUS/MX-----------------
MODE METER SETP MAIN
STATUS/MX/MODE---P00
charger mode: Silent
DOWN STATUS PORT
STATUS/MX/MODE---P00
aux relay Low Batt
mode
DOWN UP TOP PORT
STATUS/MX/MODE---P00
aux relay state: ON
DOWN UP TOP PORT
STATUS/MX/MODE-------
end of mode menu
UP TOP STATUS
STATUS/MX-----------------
MODE METER SETP MAIN
