21
CHARGER SETUP
This screen allows changes to the MX60’s recharging voltage set points (Current Limit,
Absorb, Float):
• The presently selected numerical value will have an asterisk “ * ” to the left of it.
• Pressing selects the value to be changed.
• You may need to re-enter the password to change these settings.
• The default charger output current limit setting is 60 amps and is adjustable up to 70 amps. At 70
amps, a 70A or 80A breaker must be used between the battery and the MX60.
• Change ABSORB and FLOAT set points using this screen if the battery manufacturer’s
recommendations are di erent than the default values. Otherwise, see page 80 for suggested
recharging voltage set points.
• If a battery remote temperature sensor (RTS) is used, its compensated voltage values can be viewed
in the MISCELLANEOUS (Misc) screen under the Tmp Comp heading.
NOTE: If an RTS is used, set the ABSORB and FLOAT setting
voltage based on a 25°C / 77°F setting. These are typically
the manufacturer’s set points (always consult the battery
manufacturer’s recommendations). If an RTS is not in use,
please see the Non-Battery Temperature Compensated
System values (page 86) and adjust the ABSORB/FLOAT
values accordingly.
LIMIT ABSORB FLOAT
Amps Volts Volts
*60.0 14.4 13.6
EXIT - +
