LOG2
The Log2 screen displays additional voltage and time information.
Daily high Voc value
Daily peak
battery voltage
Operational mode
The Hi(ghest) Voc seen by the MX60
Sunrise shows how long
ago the MX60 woke up
for the rst time each day
and when the daily and
total logged values were
updated and cleared from
the STATUS screen.
Pressing and holding the #3 soft key
toggles 24/25 hour save mode. Soft key
#4 addresses Auto RESTART mode.
PkBatV logs the peak battery voltage and operational mode simultaneously, updating daily at rst
wakeup; it can also be reset to the present battery voltage by powering o the controller. This
helps determine any degree of voltage overshooting. The peak battery voltage should not be used
to identify that the controller has charged the battery to a higher voltage than its regulation set
point.
NOTE: If controller power is disconnected, the BatTmpErr becomes the default operational mode
until the controller wakes up.
PkBatV Voc HiVoc
012.2 070.2 076.9
B-MPPT Sunrise
EXIT NEXT 00:06:12
