48
Wakeup Mode selects how often the MX60 does a Wakeup
during “Snoozing” periods. Since environmental condition
impact the open circuit voltage (Voc) of an array, a user
selectable Voc rise in value will allow the controller to
Wakeup sooner or later based on the last measured Voc
value. A selectable delay time in minutes will also allow
the controller to Wakeup sooner or later if the measured
Voc did not meet the user selectable Voc rise in value.
Before changing these values, monitor your system for a
week or so using the factory defaults and then gradually
adjust the set points. If they’re set too high, the MX60
might not wake up soon or often enough, which means
a loss of power production. Note: +VOC ranges from 1.5V
up to 9.5V. +MIN ranges from 5 up to 15 minutes. Press
the <EXIT> soft key to return to the MAIN Menu.
From the MAIN Menu, press the < > soft key to move the
asterisk next to the Logging function and then press the
<GO> soft key.
ADVANCED MENU
Wakeup Mode
01.5v 05m
EXIT NEXT +VOC +Min
Charger Aux Light
Eq Misc *Advanced
Logging Log2
EXIT GO
