MISC—MISCELLANEOUS
The MISCELLANEOUS screens display extra settings and technical information, some of which is
useful for OutBack Power Systems Technical Services.
The GT (Grid-tie) value is sent from
GT series inverter through the MATE
and HUB for Grid-tie control com-
munications. GT X means the MX60 is
in grid-tie mode and communicating
with the G Series Inverter.
Each MPPT operation is
a state. This number
is useful for OutBack
troubleshooting.
This is the duty cycle of
the converter. At 50%,
the PV terminals would
be twice the battery
voltage.
The Bulk/Absorb
charge timer counts
up in Bulk and counts
down in Absorb.
The battery temperature
compensated Absorb (a)
and Float (f) set points
rise and fall with tem-
perature. If no RTS is used,
these settings will be
the same as those in the
charger setting screen.
Press <NEXT> to
Continue to the
Force Bulk/Float
screen.
This soft key covers normal and
limited battery compensation
voltage range. Press WIDE and
LMIT mode appears, which limits
the Upper and Lower battery-
compensated voltage range.
RSTRT forces the MX60 to restart or
wake-up from 5- minute (default)
long Snoozing mode. Restart and
wakeup are mainly service features.
GT State PWM% ChgT
255 07 50.0 005
Tmp Comp a14.4 f13.6
EXIT NEXT WIDE RSTRT
