46
Low Cuto sets the battery charger’s lowest allowable
current limit the MX60 will charge in MPPT mode before
stopping and returning to Snoozing. The Low Cuto is
adjustable from .2 amps to 1 amp; .6 amps is the default
Low Cuto current. Raising this value will assist the MX60
in entering Sleeping mode at night. Press the <+Amp>
soft key to raise this limit. When nished, press the
<NEXT> soft key to view the MPPT Mode screen.
This screen allows the user to choose one of these
modes:
• Auto Sweep MPPT Mode (the default and preferred
mode), which sweeps the PV upon wakeup and then
does mini Sweeps from that point on at the selected
Sweep Interval. If the sweep interval is set at 0 minutes,
the MX60 awakes every 1.5 hours and does a full
sweep. Auto Restart applies here as well (see LOG2 Auto
Restart, page 52).
• U-Pick % (Voc) MPPT mode operates the PV voltage at a
user-selected percentage of the Voc which is displayed
in the Park Mpp % Voc screen. U_Pick % acquires a
new Voc value every Sweep Interval. If the mini-sweep
interval is set to 0 minutes, a new Voc may be acquired
once every 1.5 hrs. depending on the Auto Restart
setting (see LOG2 Auto Restart, page 52). This is an
alternative to the Auto Sweep mode and may also be
useful for micro-hydro applications.
Press the <MODE> soft key to choose an MPPT mode
and the <nonGT> soft key if you have an OutBack GT
series inverter system with a HUB and MATE. Press the
<NEXT> soft key to view the Absorb Time Limits screen
The default value is nonGT or
non-grid-tied. Select GT mode if
you have a GVFX or GTFX inverter,
MATE and HUB connected to
the MX60. Selecting GT estab-
lishes the proper grid-tie mode
communications between the
G-series FX and the MX60.
ADVANCED MENU
Low Cutoff
< .6 Amp
EXIT NEXT +AMP
ADVANCED MENU
MPPT Mode
Auto Sweep
EXIT NEXT nonGT MODE
