Fuses
356
X
Closing: Hook cover 1 into the opening at
the front.
X
Press cover 1 back on until it engages.
!
The fuse box cover must be properly
positioned as described to prevent
moisture or dirt from entering the fuse box
and possibly impairing fuse operation.
Fuse box in trunk
CLK coupe
The fuse box is located in the trunk behind the
left-hand trim panel.
1
Trim panel
2
Fuse box cover
X
Open the trunk.
X
Opening: Pull away trim panel 1.
X
Remove fuse box cover 2.
X
Closing: Place fuse box cover 2 back on.
X
Press trim panel 1 back into place.
CLK cabriolet
The fuse box is located in the trunk behind the
left-hand trim panel.
1
Trim panel
X
Open the trunk.
X
Opening: To open, pull trim panel 1 in the
direction of the rear light and outward.
X
Closing: Press trim panel 1 back into
place.
Fuse box in engine compartment
The fuse box is located in the engine
compartment on the driver’s side.
X
Open the hood.
1
Cover
2
Screw
3
Retainer
X
Removing cover: Twist screws 2 90°
counterclockwise.
X
Lift the rear of cover 1.
X
Slide out retainer 3 and remove cover
1 by pulling towards front.
Practical hints
