Climate control system
187
Adjusting air distribution
The air distribution can be adjusted
separately on each side of the passenger
compartment
10
.
The symbols on the control represent the
following functions:
Symbol Function
Z
Directs air to the windshield and
through the side defroster air
vents
b
Directs air into the entire
vehicle interior
Y
Directs air to the footwells and
through the side air vents
a
Directs air through the center
and side air vents
Climate control
The air distribution can be adjusted manually.
X
Turn air distribution control 4
(Y page 179) to the desired symbol.
The air distribution is adjusted according to
the chosen setting.
You can also turn the control to a position
between two symbols.
Automatic climate control
X
Turn air distribution control 1 or 8
(Y page 181) to the desired symbol.
The indicator lamp in button U goes out.
The automatic air distribution is switched
off. The air distribution is adjusted
according to the chosen setting.
You can also turn the control to a position
between two symbols.
Adjusting air volume
Climate control
X
Decrease/increase: Turn air volume
control 1 (Y page 179) clockwise or
counterclockwise.
Automatic climate control
X
Decrease/increase: Press button · or
Q.
Front defroster
You can use this setting to defrost the
windshield, for example if it is iced up.
You can also defog the windshield and the
side windows.
i
Keep this setting selected only until the
windshield or the side windows are clear
again.
10
Vehicles with automatic climate control
Controls in detail
