Tires and wheels
247
Tire Pressure Monitor
Restarted
After driving a few minutes the system
verifies that the current tire inflation
pressures are within the system’s specified
range. Afterwards, the current tire inflation
pressures are accepted as reference values
and then monitored.
X
If you wish to cancel: Press button
ç.
MOExtended system
The MOExtended system allows you to
continue driving your vehicle even if there is
a total loss of pressure in one or more tires.
You may only use the MOExtended system in
conjunction with the Run Flat Indicator
(Y page 243) or the TPMS (Y page 244).
For information on driving in case of pressure
loss in one or more tires (emergency mode),
see the “Practical Hints” section
(Y page 346).
Tire labeling
Besides tire name (sales designation) and
manufacturer name, a number of markings
can be found on a tire.
Following are some explanations for the
markings on your vehicle’s tires:
1
Uniform Tire Quality Grading Standards
(Y page 253)
2
DOT, Tire Identification Number
(Y page 251)
3
Maximum tire load (Y page 251)
4
Maximum tire inflation pressure
(Y page 252)
5
Manufacturer
6
Tire ply material (Y page 254)
7
Tire size designation, load and speed
rating (Y page 247)
8
Load identification (Y page 250)
9
Tire name
i
For illustration purposes only. Actual data
on tires are specific to each vehicle and
may vary from data shown in above
illustration.
For more information, see “Rims and
tires” (Y page 365).
Tire size designation, load and speed
rating
1
Tire width
2
Aspect ratio in %
Operation
Z
