Loading and storing
203
7
Hook
8
Eye
X
Connect hook 7 to eye 8 located on
center tunnel in front of rear seat bench.
X
Tighten strap by pulling at the loose end
(arrow).
Unloading and folding
X
Loosen both straps.
X
Disconnect hook 7 from eye 8.
X
Unload skis.
X
Close flap in trunk.
X
Fold and flatten ski bag lengthwise.
X
Place folded ski bag inside recess of seat
backrest.
X
Fasten hook and loop fastener.
X
Close cover.
X
Fold rear armrest up.
Closing ski bag roller blind
(CLK cabriolet)
1
Left hinge
2
Right hinge
3
Pull strap
X
Pull ski bag roller blind downward using pull
strap 3.
X
Manually fold left 1 and right hinges 2 of
ski bag roller blind all the way down.
X
To snap ski bag roller blind into place, press
left and right hinges where the word PRESS
can be seen.
X
Fold luggage cover back and close it
securely (Y page 197).
Controls in detail
