Instrument cluster
33
Function Page
1 L Left turn signal
indicator lamp
98
2
v ESP
®
warning lamp
313
3 Speedometer
4 Multifunction display
124
5 l Distance warning
lamp
1
6 K Right turn signal
indicator lamp
98
7 Coolant temperature
indicator with:
Ì Coolant temperature
warning lamp 316
8 Tachometer with:
1 Supplemental
Restraint System (SRS)
indicator lamp
41,
312
- Antilock Brake
System (ABS) indicator
lamp
309
Function Page
< Seat belt telltale
311
A High-beam headlamp
indicator lamp
98
B Low-beam headlamp
indicator lamp
96
9 Main odometer with:
Transmission position
indicator/gear range
indicator
114,
115
Program mode indicator 116
a Clock with:
; Brake warning lamp,
USA only
310
3 Brake warning lamp,
Canada only
310
? Engine malfunction
indicator lamp, USA only
315
± Engine malfunction
indicator lamp, Canada only
315
Function Page
H Combination low tire
pressure/TPMS
malfunction telltale, USA
only
244,
317
\ Roll bar warning lamp
(CLK cabriolet)
314
b Fuel display with:
4 Fuel tank reserve
warning lamp 314
c Reset button for:
Resetting trip odometer 122
Adjusting instrument
cluster illumination 121
Confirming new time
settings 135
1
Warning lamp without function. It illuminates when the ignition is on. It should go out when the engine is running.
At a glance
