For that sector enter:
A21 USER VALUE 230° ( 50
°
+ 180
°
); 50° is the symmetric axis between the two radials (30° + 20° = 50°,
because the complete sector has 40
°
)
A1 20°, because the sector angle is 40
°
R1 is 20km
A2 and R2 are 0
2.4.4.2 Starting a task
If the glider is flying into the start sector and the pilot decides to start the task, the following steps must be followed to
start the task:
Wait until the message INSIDE appears, indicating that the glider is in the start sector
Press the START button (short press)
A task cannot be started on the ground. Pressing the START button (about 1 sec press), starts the task. A indication
that the task has started is that the navigation data changes to the first TP.
It is also possible to start a task, while the glider is outside the start sector. In this case the pilot has to press START for
a longer time (about 6 sec., but in any case long enough until the TSK navigation data to the first TP appears).
Once the task has been started, it can be terminated at any time during flight and a new start made. If a task has already
been started, press ENTER and the following screen will appear:
Before start After start
Navigation to 1. TP
Radial 30
0
Radial 70
0
Turn point
