Replacing wiper blades
353
Vehicles with SmartKey
X
Turn the SmartKey in the starter switch to
position 1.
X
Turn combination switch to wiper setting
u.
X
With wiper arms in vertical position, turn
the SmartKey in the starter switch to
position 0.
X
Remove the SmartKey from the starter
switch.
Vehicles with KEYLESS-GO
X
Turn off the engine.
With the driver’s door closed, the starter
switch is now in position 1.
X
Turn combination switch to wiper setting
u.
X
With wiper arms in vertical position, open
the driver’s door.
The starter switch is set to position 0, same
as the SmartKey removed from the starter
switch.
X
Turn combination switch to wiper setting
M.
Removing wiper blades
Front wiper blades
!
Do not pull on the wiper blade inserts.
They could tear.
X
Fold the wiper arms forward until they
engage.
X
Turn the wiper blade at a right angle to the
wiper arm.
X
Slide the wiper blade sideways out of the
retainer.
Rear wiper blade (wagon)
!
Do not pull on the wiper blade insert. It
could tear.
1
Wiper blade
2
Tab
3
Attachment
4
Removing
X
Fold the wiper arm away from the rear
window until it engages.
X
Turn wiper blade 1 at a right angle to wiper
arm.
X
Press tab 2 down and push wiper blade
1 downward in direction of arrow 4.
X
Remove wiper blade 1.
Practical hints
