Loading and storing
207
X
Fold seat cushion 1 rearward and press
the center front of the cushion until it
audibly engages.
X
If need be, fold the head restraint forward
by hand.
Removing rear seat cushion
Removing the rear seat cushions will provide
you with a larger, flat cargo volume.
X
Fold the seat cushions forward
(Y page 205).
X
Remove the head restraints (Y page 100).
X
Fold the seat backrest into the vertical
position.
1
Release lever
2
Plug for rear seat heating (Canada only)
!
Vehicles with rear seat heating (Canada
only):
The electrical contact on the bottom of the
seat cushion must be disconnected before
removing the rear seat cushion.
X
Press the plug connection on the
checkered surface and pull plug 2 for the
seat heating out of the seat cushion.
i
Vehicles with rear seat heating (Canada
only):
When placing the seat cushion back in,
guide the plug connection back together
until the plug engages.
X
Pull release lever 1 and remove the seat
cushion by pulling it upward.
!
Leave the seat cushion hinge in this
position. The upholstery could be damaged
if you fold the hinge back.
X
Fold the seat backrest forward.
Wagon
!
To prevent damage, the following must be
observed before folding the seat backrest
forward:
R
the head restraints must be folded back
and fully inserted
R
the front seat must be moved forward
until sufficient clearance for folding
procedure is achieved
R
the seat cushions must be folded forward
Controls in detail
