Loading and storing
213
Storage box 1 is additionally held in place
from above by the twin roller blind.
X
Loading: Fold seat backrests 3 forward
(Y page 207).
X
Fill storage box 1 with cargo through the
opening on the front side.
X
Fold seat backrests 3 to the original
position (Y page 208).
X
Removing: Fold seat backrests 3 forward
(Y page 207).
X
Slide locking hooks 4 of storage box 1
forward out of the retainers.
X
Pull storage box 1 to the rear and remove
it from cargo compartment.
X
Fold seat backrest 3 to the original
position (Y page 208).
Twin roller blind (wagon)
The twin roller blind contains a cargo net and
a cargo compartment cover.
Cargo net
G
Warning!
The cargo net cannot hold back heavy
loads. The transported load should
therefore always be tied down.
Objects which are insufficiently secured
could otherwise injure you if they are
thrown around in the event of an accident,
during hard braking or steering maneuvers.
1
Cargo net
2
Mounting for cargo net
X
Pull cargo net 1 up and hook it onto
mounting 2.
i
You can use cargo net 1 even when the
seat backrest is folded forward. Cargo net
1 should then be hooked onto the front
mountings.
Cargo compartment cover
To assist loading the cargo area when the
cargo compartment cover is closed, the cover
will be released and automatically raised/
lowered when opening/closing the tailgate.
!
When loading the vehicle, make sure not
to load the cargo compartment over the
lower edge of the side windows.
The twin roller blind could otherwise be
damaged when the tailgate is being closed.
