Benz Center for the corresponding data of all
special bodies and special equipment.
Engine SLS AMG (197)
Engine, type
159
Mode of operation
4-stroke engine,
gasoline injection
No. of cylinders
8
Bore
4.02 in (102.20 mm)
Stroke
3.72 in (94.60 mm)
Total piston
displacement
378.8 cu in
(6 208 cm
3
)
Compression
ratio
11.3:1
Output acc. to
SAE J 1349
12
563 hp/6 800 rpm
(420 kW/6 800 rpm)
Maximum torque
acc. to SAE J 1349
465 lb-ft/
5 200 rpm
(630 Nm/
5 200 rpm)
Maximum engine
speed
7 200 rpm
Firing order
1-5-4-2-6-3-7-8
Poly-V-belt
2 360 mm
Electrical system SLS AMG (197)
Alternator
14 V/180 A
Starter motor
12 V/1.7 kW
Battery
12 V/80 Ah
Spark plugs, type
NGK ILZKAR 7A10
Spark plugs,
electrode gap
0.039 in (1.0 mm)
Spark plugs,
tightening torque
15 - 18 lb-ft
(20 - 25 Nm)
Main dimensions SLS AMG (197)
Overall vehicle
length
182.7 in (4 640 mm)
Overall vehicle
width
13
81.8 in (2 078 mm)
Overall vehicle
height
49.7 in (1 262 mm)
Wheelbase
105.5 in (2 680 mm)
Track, front
66.2 in (1 682 mm)
Track, rear
65.0 in (1 651 mm)
Ground clearance
3.7 in (95 mm)
Turning circle
36.1 ft (11.0 m)
Weights SLS AMG (197)
Trunk load
max. 137 lb (62 kg)
Rims and tires
Notes
!
Only use tires which have been tested and
approved by Mercedes-Benz. Tires
approved by Mercedes-Benz are developed
to provide best possible performance in
conjunction with the driving safety systems
on your vehicle such as the ABS or the ESC.
Tires specially developed for your vehicle
and tested and approved by Mercedes-
Benz can be identified by finding the
following on the tire’s sidewall:
R
MO = Mercedes-Benz Original
equipment tires
Using tires other than those approved by
Mercedes-Benz may result in damage that
is not covered by the Mercedes-Benz
Limited Warranty.
12
Premium fuel required. Performance may vary with fuel octane rating.
13
Exterior rear view mirrors folded out.
