Opening side air vent: Turn the cross in
side air vent ? in the direction of the arrow
to position 1.
X
Closing side air vent: Turn the cross in
side air vent ? in the direction of the arrow
to position 2.
i
Side air vent ? is never closed
completely, even when side defroster air
vent = is closed.
Adjusting air distribution
The symbols shown in display H
(Y page 298) on the climate control panel
represent the following functions:
Symbol Function
¯
Directs air through the
defroster air vents to the
windshield and door windows
P
Directs air through the center
and side air vents
O
Directs air to the footwells
N
Directs air through the center
and side air vents and to the
footwells (USA only)
_
Directs air into the entire
vehicle interior (Canada only)
b
Directs air through the center,
side and defroster air vents to
the windshield and door
windows (Canada only)
a
Directs air through the
defroster air vents to the
windshield and door windows
and to the footwells
X
Press button _ repeatedly until you
have select the desired setting and the
corresponding symbol is shown in display
H.
Adjusting air volume
X
Decreasing/increasing: Press button
I or K.
Front defroster
You can use this setting to defrost the
windshield, for example if it is iced up.
You can also defog the windshield and the
door windows.
i
Keep this setting selected only until the
windshield or the door windows are clear
again.
X
Activating: Press button ¬.
The indicator lamp in the button comes on.
The climate control switches to the following
functions automatically:
R
cooling on to dehumidify
R
most efficient blower speed and heating
power, depending on outside temperature
R
air flows onto the windshield and the door
windows
R
the air recirculation mode is switched off
i
You can adjust the air volume when the
front defroster is switched on.
X
Deactivating: Press button ¬ again.
The indicator lamp in the button goes out.
The previous settings are once again in
effect. The cooling remains switched on.
The air recirculation remains switched off.
or
X
Press button Ã.
The indicator lamp in button ¬ goes out.
Air volume and air distribution are adjusted
automatically.
i
To deactivate defrosting, you can also
press button ^ or turn temperature
controls.
302
Climate control system
Controls in detail
