Real-Time Traffic Notification Symbols
Symbol Description Traffic Notifications in Map Display Traffic
Report
Lists
Traffic
Report
Message
Warning
(red)
Appears at the beginning of the
affected road section if route guidance
is active and route goes through the
event area.
Appears
with
warning
entry type
Appears
with
warning
entry type
Incident
(yellow)
Appears at the beginning of the
affected road section if route guidance
is active and route goes through the
incident area.
Appears
with
incident
entry type
Appears
with
incident
entry type
Traffic jam
on route
(Speed and
flow)
Appears at the beginning of traffic
congestion (average speed
25 – 45 mph) if route guidance is active
and route goes through congested
area.
Yellow car symbols could appear in
combination with this symbol.
Appears
with traffic
jam on
route (stop
and go)
entry type
Appears
with
traffic jam
on route
(stop and
go) entry
type
Traffic jam
on route
(Speed and
flow)
Appears at the beginning of traffic
congestion (average speed 5 – 20 mph)
if route guidance is active and route
goes through congested area.
Red car symbols could appear in
combination with this symbol.
Appears
with Traffic
jam on
route entry
type
Appears
with
Traffic
jam on
route
entry type
Blocked
section on
route
Appears at the beginning of a blocked
area if route guidance is active and
route goes through blocked area.
X X X X symbols could appear in
combination with this symbol.
Appears
with
Blocked
section
entry type
Appears
with
Blocked
section
entry type
Yellow
line with
arrows
Incidents Possible obstacles for traffic flow (e.g.
road work)
Appears on the affected side
(direction) of the road
(Not
possible)
(Not
possible)
140
Navigation (Traffic Messages)
