Windshield fogged on the outside
X
Switch the windshield wipers on
(Y page 253).
If the automatic mode of the climate control
is switched off:
X
Press button _ repeatedly until one of
the following symbols P or O
appears in display H (Y page 298).
Maximum cooling MAX COOL
MAX COOL is only available in U.S. vehicles.
MAX COOL is only operational when the
engine is running.
You can use this setting to provide the fastest
possible cooling of the vehicle interior (when
windows are closed).
X
Activating: Press button Ù.
The indicator lamp in the button comes on.
The climate control switches automatically to
the following functions:
R
maximum cooling
R
maximum blowing power
R
the air recirculation mode is switched on
X
Deactivating: Press button Ù again.
The indicator lamp in the button goes out.
The previous settings are once again in
effect.
i
To switch the maximum cooling function
off, you can also press button ^, Ã
or ¬.
Air recirculation mode
Switch to air recirculation mode to prevent
unpleasant odors from entering the vehicle
from the outside (e. g. before driving through
a tunnel). This setting cuts off the intake of
outside air and recirculates the air in the
passenger compartment.
G
Warning!
Fogged windows impair visibility,
endangering you and others. If the windows
begin to fog on the inside, switching off the
air recirculation mode immediately should
clear interior window fogging. If interior
window fogging persists, make sure the air
conditioning is activated, or press button
¬.
X
Activating: Press button g.
The indicator lamp in the button comes on.
i
The air recirculation mode is activated
automatically at high outside
temperatures.
The indicator lamp in button g is not lit
when the air recirculation mode is switched
on automatically.
A quantity of outside air is added after
approximately 30 minutes.
X
Deactivating: Press button g again.
The indicator lamp in the button goes out.
i The manually selected air recirculation
mode is deactivated automatically:
R
after 5 minutes if the outside
temperature is below approximately
41‡ (5†)
R
after 5 minutes if the air conditioning is
turned off
R
after 30 minutes if the outside
temperature is above approximately
41‡ (5†)
Using driver-side settings for
passenger side
This feature is only available in Canada
vehicles.
You can use the settings of the driver’s side,
such as temperature, air volume and air
distribution, for the passenger side.
Climate control system
303
Controls in detail
