APPENDIX
A
-3
PORT
SETUP
2
4
SYSTEM
SETUP
3
SELECT SNTNC soft key*
GPS/NMEA
PORT
FURUNO GPS SENSOR
(YES, NO)
OUTPUT FORMAT
(NMEA 0183 Ver.1.5, 2.0)
LAT/LON FORMAT
(DD° MM. MM’
DD° MM. MMM’
DD° MM. MMMM’)
OUTPUT DESTINATION
(YES, NO)
OUTPUT THROUGH NETWORK
(Select data sentences to output to NavNet
equipment. See * below. All sentences turned off in default setting.)
PC/NMEA/
EXT. BUZZ
PORT
NMEA OUTPUT FORMAT
(NMEA 0183 Ver.1.5, 2.0)
BAUD RATE
(4800, 9600, 19200,
bps))
BIT LENGTH (7 bits, 8 bits)
STOP BIT (1 bit, 2 bits)
PARITY
(EVEN, ODD, NONE)
SELECT SNTNC soft key*
* = AAM, APB, BOD, BWR(BWC)#1, DPT(DBT)#2, GGA, GLL, GTD,
MTW, RMA, RMB, RMC, VHW, VTG, WPL, XTE, ZDA, HDT, HDG, MWV
SELECT SNTNC soft key*
NMEA PORT
FURUNO GPS SENSOR
(YES, NO)
OUTPUT FORMAT
(NMEA 0183 Ver.1.5, 2.0)
LAT/LON FORMAT
(DD° MM. MM’
DD° MM. MMM’
DD° MM. MMMM’)
OUTPUT DESTINATION
(YES, NO)
#1= BWR for rhumb line, BWC for great circle
#2 = DBT for NMEA Ver. 1.5; DPT for NMEA Ver. 2.0
