3. PLOTTER OPERATION
3-25
3.7 Marks, Lines
Marks are useful for denoting important points such as a good fishing spot.
Marks can be inscribed in seven shapes and seven colors: Red, yellow, green,
light-blue, purple, blue and white.
✕
3.7.1 Entering a mark, line
1. Place the cursor where you want a mark to appear.
2. Press the [SHOW/HIDE] key (if necessary) followed by the MARK ENTRY
soft key.
The mark is inscribed in the size, color and shape selected on the mark & line
menu. The default mark attributes are size, large; color, yellow, and shape,
hollow circle (
○).
3.7.2 Changing mark attributes
You can select the shape, size and color for marks on the MARKS & LINES
menu.
1. Press the [MENU] key to show the menu.
2. Press the CHART SETUP, TRACKS & MARKS CONTROL and MARK
SETUP soft keys to show the MARKS & LINES menu.
MARKS &
LINES
EDIT
RETURN
MARKS/LINES COLOR YELLOW
MARKS SHAPE
LINES STYLE
.
MARKS SIZE LARGE
SHIP’S TRACK STATUS
TRACKING
TRACK: 1234/2000
MARK : 9/6000
Marks & lines menu
3. Select MARKS/LINES COLOR, then press the EDIT soft key.
4. Use the trackball to choose color desired (default setting: yellow).
5. Press the ENTER soft key.
6. Select MARKS SHAPE, then press the EDIT soft key.
