06 Starting and driving
143
Load on the roof
06
Fitting load carriers
Make sure the load carrier is fitted in the
right direction (see the marking on the
decal under the cover).
Fit the guide pins into the guide holes (1).
Carefully lower the bracket on the other
side to the roof.
Screw the knob up a bit.
Press the knob against the roof bracket
and catch the hook in the roof bracket
under the roof rail.
Screw the load carrier in place.
Fit the guide pins of the other brackets
into the guide holes.
Screw the load carrier in place.
Check that the hook is properly secured in
the roof bracket.
Tighten the knobs alternately until the car-
rier feels secure.
Replace the cover.
Check that the roof rack is properly se-
cured.
NOTE
Check the knobs regularly to see that they
are properly tightened.
