1.4 Chapter 1 Introduction
Flip-Up GPS Antenna
(open parallel with
horizon for GPS
navigation)
Reset Button
Speaker
Back View
An additional connection is made from the back of the cradle’s USB port connector to the AC adapter which plugs into any AC
outlet.
• Reset Button: Under normal use, you should not have to use the reset button. See “Resetting your iQue
®
” later in this
chapter for information on when and how to use the reset button.
• Flip-up Integrated GPS Antenna: Open for satellite reception and GPS navigation. Open for satellite reception and GPS
navigation. To extend battery life, keep the antenna closed when you are not using the iQue for navigation.
NOTE: This antenna is designed to best receive satellite signals when it is aligned parallel with the horizon. If
the antenna is positioned vertically, the iQue’s ability to receive satellites may be dramatically reduced.
• Speaker: Internal speaker for listening to voice-guided navigation commands.
USING THE STYLUS
Just as you use a mouse pointer to click elements on your computer’s screen, you use the stylus to tap elements on your
handheld’s touch-sensitive screen. Tapping is the basic action used to execute tasks on your handheld.
IMPORTANT: Always use the point of the stylus for tapping or making strokes on the handheld screen. Do not
use a pen, pencil, or any other sharp object to write on the handheld screen. If you misplace your stylus, visit
www.garmin.com for information on a replacement.
With your handheld turned on, you can tap the handheld screen to perform many operations, such as the following:
• Open applications.
• Choose menu commands.
• Initiate a Find operation.
• Select options in dialog boxes.
• Open the on-screen keyboards.
Just as you drag the mouse to select text or move objects on your computer, you can drag the stylus to select text. In addition,
you can use the stylus to drag the slider of any scroll bar.
Introduction: Using the Stylus
