APPENDIX
A
P-31
Antenna unit RSB-103/104/105 (FAR-2827W)
FURUNO
Model
FAR-2827W
Unit
Antenna Unit RSB-104/105
ELECTRICAL PARTS LIST
SYMBOL NAME REMARKS
PRINTED CIRCUIT BOARD
TB 03P9349
BP GEN 03P9347
MOTOR
D8G-516
2003/10
Transceiver unit RTR-081 (FAR-2827W)
FURUNO Model FAR-2827W
Unit Transceiver Unit RTR-081
ELECTRICAL PARTS LIST
SYMBOL NAME REMARKS
PRINTED CIRCUIT BOARD
TB 03P9349
IF AMP 03P9335
PWR 03P9348
MD 03P9244
RFC 03P9346
MIC ASSEMBLY
RU-9601
MOTOR
24 rpm
DIODE LIMITER
RU-9099
CIRCULATOR
RC-3686
PULSE TRANSFORMER
RT-9023
MAGNETRON
MG5436
2007/11
109P0824H602
ISOLATOR
FX0157
