©2011 Edelbrock LLC
Part #1596, 1597, 1598 & 1599
Brochure #63-1598
Rev. 2/11 - AJ/mc
Edelbrock E-Force Supercharger System for
the 2010 Camaro SS
Installation Instructions
Page 3
Bag #1
Bag #2
(2x) - M8 Washer
(3x) - M8 x 1.25 x 20mm
Hex Flange Bolt
(1x) - M10 x 1.5 x 65mm Hex Flange Bolt
(1x) - M10 x 1.5 x 65mm Socket Head Bolt
(3x) - M8 x 1.25 x 100mm Socket Head Bolt
(1x) - M8 x 1.25 x 30mm Hex Flange Bolt
(4x) - M6 x 1 x 16mm
Hex Flange Bolt
(4x) - M8 x 1.25 x 20mm
Hex Flange Bolt
(4x) - M8 x 1.25
Hex Flange Nut
(1x) - Lower Intercooler Reservoir Bracket
(1x) - Upper Intercooler Reservoir Bracket
(2x) - 1/2” Hose Clamp
(7x) - 3/4” Hose Clamp
INSTALLATION HARDWARE IDENTIFICATION GUIDE
(1x) - M6 x 1 x 25mm Hex Stand-Off
(2x) - Nylon Body Pin
