©2011 Edelbrock LLC
Part #1596, 1597, 1598 & 1599
Brochure #63-1598
Rev. 2/11 - AJ/mc
Edelbrock E-Force Supercharger System for
the 2010 Camaro SS
Installation Instructions
Page 1
Edelbrock LLC, 2700 California Street, Torrance, CA 90503
Toll-Free Tech Line: 1-800-416-8628 Office/Sales Line: 310-781-2222
Thank you for purchasing the Edelbrock 6.2L GM Supercharger System for the 2010 Chevy Camaro. The Edelbrock E-
Force Supercharger System for the 2010 Camaro SS utilizes Eaton’s new Gen VI TVS Supercharger rotors, featuring a four
lobe design with a full 160 deg. of twist for maximum flow, minimum temperature rise, quiet operation, and the reliability
for which Eaton is known. The Edelbrock Supercharger is a complete system that maximizes efficiency and performance
by minimizing air restriction into, and out of, the supercharger. This results in maximum airflow, with minimal temperature
rise and power consumption. The supercharger housing itself is integrated into the intake manifold for a seamless design
with minimal components, eliminating the possibility of vacuum leaks between gasket surfaces. The system also utilizes
a front drive, front inlet configuration giving it the shortest, least restrictive inlet path on the market. The supercharger is
inverted, expelling the air upward. Air pressure then builds in the plenum, before being drawn down through each of two
intercooler cores, oriented horizontally, next to, and below the supercharger outlet. After passing through the intercooler
cores, the air travels through the long 12” individual intake runners, which route underneath the supercharger housing to
the cylinder head ports, in a horizontal, nested configuration. The upper plenum area is enclosed by a top cover that has
been designed to provide an appealing and distinctive under-hood appearance. This configuration allows for a compact
package that can fit under the stock hood and cowl of the Camaro, without sacrificing runner length, or intercooler area.
The E-Force supercharger features a uniquely styled plenum, and includes matching side covers. The Edelbrock
supercharger provides neck snapping performance that is safe to operate on a completely stock engine. It is 50-state
emissions legal, and can be had with an optional 5-year 100,000 mile warranty so that there are no worries when
installing it on a brand new car.
INTRODUCTION
TOOLS REQUIRED
Jack and Jack Stands
OR Service Lift
Panel Puller
Ratchet and Socket Set including: 7mm, 8mm, 10mm
(standard, deep and universal), 12mm (deep), 13mm,
15mm (deep), 18mm, 21mm (deep), 24mm
Wrenches including: 8mm, 13mm, 16mm, 18mm,
13/16”, 3/4”
Crescent Wrench
12” Ratchet Extension Bar
1/2” Breaker Bar
Flat Blade & Philips Screwdrivers
Compressed Air
Torx-20 Driver
Allen Wrenches including: 6mm, 8mm
3/8” Fuel Line Removal Tool
Torque Wrench
Needle Nose Pliers
Pliers
OR Hose Clamp Removal Tool
Pneumatic or Power Drill
1-1/8” or larger Uni-bit
Impact Wrench
Red & Blue Loctite or equivalent
O-ring Lube
Thread Sealing Compound
Anti-sieze
Masking Tape
J-42386-A Flywheel Holding Tool
Soldering Iron
