294 Parts and diagrams Q1860-90918
Numerical parts list
Table 89. Numerical parts list
Part number Description Figure and page
Q1860-67904 Cover, front Figure 162 on page 264
Q1860-69005 Dc controller Figure 176 on page 280
Q1860-69010 Duplexer Figure 184 on page 289
Q1860-69008 Fuser, exchange (100-120V) Figure 178 on page 282
Q1860-69009 Fuser, exchange (220-240V) Figure 178 on page 282
Q1860-69004 Laser/scanner assembly Figure 167 on page 271
Q1860-69006 Power supply (100 - 120V) Figure 176 on page 280
Q1860-69007 Power supply (220 - 240V) Figure 176 on page 280
C4110-40004 Overlay, English (other languages available) Figure 162 on page 264
C4117-69001 500-sheet replacement tray (exchange) Figure 181 on page 285
RB1-2190-000CN Tray 2 spring Figure 165 on page 268
RB1-6130-000CN Gear, pickup, Tray 1 Figure 165 on page 268
RB1-6134-030CN Tray 1 sensor arm Figure 162 on page 264
RB1-6141-000CN Grounding plate Figure 164 on page 266
RB1-6177-000CN Pickup shaft bushing—trays 1 and 2 Figure 165 on page 268
RB1-6179-000CN Pickup shaft bushing—trays 1 and 2 Figure 165 on page 268
RB1-6251-000CN Roller, lower-back delivery Figure 166 on page 270
RB1-7499-000CN Roller, feed, 250-sheet feeder Figure 179 on page 283
RB1-7501-020CN Lever, paper sensor Figure 179 on page 283
RB1-7503-000CN Spring, tray-size detect Figure 179 on page 283
RB1-8865-000CN D-roller Figure 182 on page 286
RB2-1731-000CN Switch rod Figure 165 on page 268
RB2-1732-000CN Door switch Figure 166 on page 270
RB2-1734-000CN Grounding plate Figure 164 on page 266
RB2-1735-000CN Grounding plate Figure 164 on page 266
RB2-1736-000CN Grounding plate Figure 165 on page 268
RB2-1739-000CN Door switch spring Figure 166 on page 270
RB2-1744-000CN On/off switch Figure 165 on page 268
RB2-1745-000CN Pin, front cover Figure 162 on page 264
RB2-1747-000CN Cover, face-down auxiliary Figure 162 on page 264
RB2-1748-000CN Cover, top Figure 163 on page 265
RB2-1749-000CN Cover, right side Figure 162 on page 264
RB2-1755-000CN Cover, right corner Figure 162 on page 264
RB2-1756-000CN Cover, left corner Figure 162 on page 264
RB2-1758-000CN Cover, control panel LED Figure 163 on page 265
RB2-1759-000CN Control panel leaf spring Figure 163 on page 265
RB2-1774-000CN Cartridge guide left Figure 165 on page 268
RB2-1775-000CN Cartridge guide right Figure 165 on page 268
RB2-1780-000CN Paper guide Figure 165 on page 268
RB2-1781-000CN Lever, registration sensor Figure 164 on page 266
RB2-1782-000CN Lever, top-of-page sensor Figure 164 on page 266
RB2-1783-000CN Spring, registration sensor Figure 164 on page 266
RB2-1784-000CN Spring, top-of-page sensor Figure 164 on page 266
RB2-1790-000CN Sensor mount (rear of controller pan) Figure 177 on page 281
