118 Removing and replacing parts Q1860-90918
4 Remove the single self-tapping screw (callout 1) that holds the control panel to the underside
of the top cover.
Figure 44. Control panel removal
5 Lift up gently on the metal plate to free the control panel.
6 Grasp the control panel by its metal frame and remove it from the underside of the top cover.
2
1
