Q1860-90918 8 Parts and diagrams 291
Toner cartridge engagement arm RB2-1856-040CN Figure 174 on page 278
Screw, TP, M3x6 XA9-0267-000CN Figure 174 on page 278
Main motor RH7-1428-000CN Figure 174 on page 278
250-sheet universal tray RG5-7188-030CN Figure 173 on page 277
Plate, length adjustment RB2-2023-000CN Figure 173 on page 277
Separation pad (does not include spring) RF5-4120-000CN Figure 173 on page 277
Spring, separation pad RS5-2439-000CN Figure 173 on page 277
Registration roller assembly RG5-4916-000CN Figure 172 on page 276
Paper feed roller assembly RG5-7084-000CN Figure 171 on page 275
Lever, registration sensor RB2-1807-000CN Figure 171 on page 275
Spring, registration sensor RB2-1808-000CN Figure 171 on page 275
Paper feed belt assembly RG5-4914-000CN Figure 170 on page 274
Large feed belt RB2-1887-000CN Figure 170 on page 274
Small paper feed belts RB2-1888-000CN Figure 170 on page 274
Transfer roller bushing cover (right) RB2-1905-000CN Figure 170 on page 274
Paper pick up roller assembly (Tray 2) RG5-3521-020CN Figure 169 on page 273
Pickup roller 250-sheet trays RB2-1821-020CN Figure 169 on page 273
Upper delivery assembly RG5-3542-090CN Figure 168 on page 272
Lever, bin-full RB2-1980-000CN Figure 168 on page 272
Gear, delivery roller RS6-0357-000CN Figure 168 on page 272
Transfer roller RG9-1542-000CN Figure 167 on page 271
Cable (fuser ac) RG5-3561-000CN Figure 167 on page 271
Cable (scanner) RG5-7072-000CN Figure 167 on page 271
Laser/scanner assembly Q1860-69004 Figure 167 on page 271
Screw, M4x16, with washer XA9-0838-000CN Figure 167 on page 271
Transfer guide assembly RF5-4118-000CN Figure 166 on page 270
Pad assembly RF5-4117-000CN Figure 166 on page 270
Door switch RB2-1732-000CN Figure 166 on page 270
Door switch spring RB2-1739-000CN Figure 166 on page 270
Roller, lower-back delivery RB1-6251-000CN Figure 166 on page 270
Roller spring, lower-back delivery RB2-2076-000CN Figure 166 on page 270
Clutch, feed rollers RH7-5346-000CN Figure 166 on page 270
Roller holder, top delivery RB2-1997-000CN Figure 166 on page 270
Roller 1, face-down guide RG9-1337-000CN Figure 166 on page 270
Roller spring, top delivery RS5-2225-020CN Figure 166 on page 270
Roller 2, face-down guide RB2-1998-000CN Figure 166 on page 270
Registration roller assembly RG5-4916-000CN Figure 166 on page 270
E-ring XD2-1100-322CN Figure 166 on page 270
Pickup roller assembly, Tray 1 RG5-3519-020CN Figure 165 on page 268
Roller, Tray 1 pickup RB2-1820-020CN Figure 165 on page 268
Power inlet assembly RG5-3545-000CN Figure 165 on page 268
Pickup shaft bushing—trays 1 and 2 RB1-6179-000CN Figure 165 on page 268
Shutter lever RF5-2421-000CN Figure 165 on page 268
On/off switch RB2-1744-000CN Figure 165 on page 268
Paper guide RB2-1780-000CN Figure 165 on page 268
Tray 1 and 2 pickup shaft left bushing RS5-1392-000CN Figure 165 on page 268
Tray 2 spring RB1-2190-000CN Figure 165 on page 268
Table 88. Alphabetical parts list (continued)
Description Part number Figure and page
